2000 SL model of Hydraulic Universal Tester form Tinius Olsen

Tinius Olsen

Model 2000SL

tinius

download

C53A4256

Automated System

The model 2000SL is designed for tension, compression, flexure and shear strength testing on materials and assemblies. The robust design that incorporates quality materials and components ensures that our reputation for superior system performance, ease of use, and longevity is maintained.

Tinius Olsen’s hydraulic testers have long been recognized as the standard for accuracy, dependability, and versatility in universal testing machines. The many thousands of testers currently in use throughout the world attest to this fact. Now more than ever, the SL series represents the highest standard in hydraulically powered universal testing machines.

Download User Instruction Manual
Please Fill the Fields to download pdf
First Name*

Last Name*

Company Name*

Job Title*

Your email*

Phone Number*

Equipment, Interested In*

Industry*

Street

Country*

State*

City*
Zip Code

How can we help?

By ticking this box I agree, in accordance with the General Data Protection Regulation (GDPR) 2018, to my personal data being stored and used by Tinius Olsen. Typically, information may be used; to identify and communicate with you, for commercial activities (including newsletters) or for marketing and business updates.
Download Brochure
Request a Proposal
Mail us

Features & Benefits

Suitable for tension, compression, transverse, shear and other tests to a maximum force of 2000kN/400,000lbf

Four-column rugged design allows larger samples to be tested

Friction-free piston operation allows smooth, controlled operation and minimal down-time

Various system interface options available, from a familiar tethered handheld interface, a wireless Bluetooth interface panel, or virtual machine controller

All interface options integrate with Horizon software

Options & Accessories

Crossheads can be closed, semi-open or fully open for easier specimen loading and unloading

Columns can be extended by up to 914mm/36in to increase test area size

Top crosshead can be made adjustable and columns can be notched to allow the adjustable top crosshead to be repositioned for more comfortable working height

In-head pocket grips can be supplied to accommodate flat or round tensile specimens

Full range of precision extensometers and deflectometers are available using video, laser, encoder, strain gauge and/or LVDT technologies

Furnaces and environmental chambers can be installed for tests at high or low temperatures

Safety enclosures with interlocks can be installed to protect operators from violent specimen breaks
